Artisan Thermostatic Surface Mounted Bar Shower Valve AR2 SHXVOFF C

Diagram ref.    Part no.        Part name
02     SCW 05588B         Screw (Grub)
03     00621763             Temperature Handle Assembly Chrome for Artisan
05     00622415             Screw In Plastic Thermostatic Cartridge
06     FILT 08410         Rubber filter washer. 24mm OD x 16mm ID.
07     WMNT10             C     Wall Mount Fixings Chrome Plated
08     NRV 08400A         Non Return Valve
09     OR 08015             O Ring (17 Mm)
10     00515129             Outlet Connector and O Ring for AR SHXMT C and AR SHXSM C
11     04048OF             Valve G1/2 for AR SHXMTFF C
12     00411087             Eco Stop for AR SHXMTFF C
13     00621764             Flow Handle Assembly Chrome for Artisan
23     00622064             Retaining washers for Non-return valve (blue & red)
24     58.9031.10000     7 l/m Flanged Green Flow Limiter for AR bar shower
